Professional Protection, Professional Sound
The PCL10PRO includes a variety of features to improve the performance and safety of your connected equipment. The high frequency filtering helps to eliminate unwanted interference from electrical sources – clean power gives you a cleaner sound. Connected equipment is protected from over-voltage and impulse voltage by the Power Conditioner’s 1 nano-second response time. Why risk an overload? Protect your equipment with the PCL10PRO.
Useful Lighting for Your Racks
Visibility doesn’t have to be a problem. The PCL10PRO features ample lighting to ensure ample visibility at any event. Two rotating pull out LED lamps are located on the front, illuminating the controls on your equipment. To ensure the cables and connections on your equipment are correct you can connect a USB powered gooseneck lamp to the connector on the back of the PCL10PRO.
Adam Hall 19” Rack Parts
The Adam Hall group began as a pioneer of flight case components, and they’ve continued in their pursuit of perfect hardware ever since. Their expertise extends to 19” rack components, and they produce a wide variety of professional quality panels, fittings, and other parts. Whether you’re looking for a new rack build, or to update an existing set up, on stage or in the studio you’re in safe hands with Adam Hall hardware.
Features
- 8 x IEC sockets and 1 x unswitched convenience socket
- High frequency filtering helps to eliminate interference
- Pull out LEDs on the front panel and USB socket for goosenecks
- 1 nano-second response time protects from voltage spikes
- Conveniently fits into 1U of standard 19” rack space
- Easy to read voltmeter and ammeter displays
Specifications
- Product type: 19” rack mains socket strips
- Type: 19” / 1 U
- Number of outlets (IEC C14): 9
- Input voltage: 230 V
- Nominal Impedance: max 10 A
- Protection Against Impulse Voltage: neutral conductor to earth, outer conductor to neutral, outer conductors to protection light
- Response Time: 1 ns
- Max. Surge Current: 6000A (8×20 µs pulse)
- Max. Surge Energy: 70 joules per contact
- Noise Cancellation:< 20 dB, 1.5 MHz-200 MHz
- Mains connector: IEC mains cord
- Fuse: 10 A
- Width: 482 mm
- Height: 44.5 mm
- Depth: 190 mm
- Weight: 3.18 kg
